Key Setting Operations Using Menus 83
To set the key priority: Press [Key Priority] or open
the M/E-1 >Misc >Key Priority menu (1173).
For details,
1
“Setting the Key Priority by a
Menu Operation” (p. 66).
Selecting the Key Fill and Key
Source
Selecting the key fill and key source
To select the key fill and key source for key 1 on the M/E-
1 bank, use the following procedure.
1
Open the M/E-1 >Key1 >Type menu (1111).
2
In the <Key Fill> group, select either of the following
for use as the key fill.
Key Bus: Signal selected on the key 1 fill bus
Matte: Signal from the dedicated color matte
generator
3
If you selected [Key Bus] in step 2, select the [KEY1]
button in the 1st row of the cross-point control block,
and select the key fill in the 2nd row.
4
If you selected [Matte] in step 2, in the Type menu,
press the [Matte Adjust] button to display the Matte
Adjust menu (1111.2), then adjust the single-color or
two-color combination color matte.
Select whether to use a single-color matte or a two-
color combination in the <Fill Matte> group in the
Matte Adjust menu.
Flat Color: Adjust color 1 with the following
parameters.
Mix Color: Carry out a color mix. Adjust color 1 and
color 2, and select a mix pattern.
For details,
1
“Executing a color mix for the key fill”
(p. 84).
5
In the <Key Source> group, specify the key source
selection mode.
Self: The key fill bus signal is automatically selected
as the key source.
When the key type is selected as chroma key,
select [Self].
Auto Select: The signal allocated, being paired with
the key fill bus signal, to a cross-point button is
automatically selected as the key source.
The pairing settings are carried out in the Setup
menu.
For details,
1
“Cross-Point Settings” (p. 329).
Split: You can select a key source signal
independently of the key source automatically
selected in Auto Select mode.
6
If you selected [Split] in step 5, select the key source
using any of the following methods.
•
In the cross-point control block, press the button in
the 2nd row while holding down the [KEY1] button
in the 1st row.
•
Press the button in the 2nd row of the cross-point
control block while holding down the [SPLIT]
button in the Flexi Pad.
•
Press the button in the 2nd row while holding down
the [KEY1] key delegation button in the transition
control block.
•
When [Split] is selected, the key memory function
(
1
p. 81) is disabled.
Notes
To select a video signal that is assigned to a cross-point
button, the operation mode for the [KEY] button must
be set.
For details,
1
“Setting the Button Operation Mode”
(p. 342).
Selecting the key source and key fill in the
menu
Selecting the key source
To select the key source, use the following procedure.
1
In the <Key Fill> group of the M/E-1 >Key1 >Type
menu (1111), select [Key Bus].
2
Press [Signal Select].
The Signal Select menu (1111.3) appears.
To Next Page
