北米Model "A3240BE-A" EDITED: 2022/ 7/ 29
& Rear window wiper blade as-
sembly
S11AZ03
1. Raise the wiper arm off the rear
window.
2. Turn the wiper blade assembly coun-
terclockwise.
3. Pull the wiper blade assembly toward
you to remove it from the wiper arm.
4. Install the wiper blade assembly to the
wiper arm. Make sure that it locks in
place.
5. Hold the wiper arm by hand and slowly
lower it in position.
& Rear window wiper blade
rubber
S11AZ04
1. Pull out the end of the blade rubber
assembly to unlock it from the plastic
support.
– CONTINUED –
Replacement of wiper blades
507
11
Maintenance and service
