Suzuki df2.5 Service Manual

2 DF2.5 “K8” (’08) MODEL
GENERAL INFORMATION
* SPECIFICATIONS * These specifications are subject to change without notice.
DIMENSIONS & WEIGHT
PERFORMANCE
POWER HEAD
Item Unit
Data
DF2.5
PRE-FIX 00251F
Overall length
(front to back)
mm (in) 437 (17.2): with tiller handle raised
Overall width
(side to side)
mm (in) 262 (10.3)
Overall height S mm (in) 963 (37.9)
Weight
(without engine oil)
Skg (lbs) 13.0 (29)
Tra n som h e igh t
S
mm
(inch type)
435 (15)
Maximum output kW (PS) 1.8 (2.5)
Recommended operating
range
r/min 5 250 – 5 750
Idle speed r/min 1 900 ± 100 (in-gear: approx. 1 500)
Engine type 4-stroke OHV
Number of cylinders 1
Bore mm (in) 48.0 (1.89)
Stroke mm (in) 38.0 (1.50)
To t al dis pl a cem en t cm
3
(cu. in) 68 (4.1)
Compression ratio : 1 9.0
Spark plug NGK CR6HSA
Ignition system Transistorized ignition
Fuel supply system Carburetor
Exhaust system Above prop exhaust
Cooling system Water cooled
Lubrication system Wet sump by trochoid pump
Starting system Manual
Choke system Manual
Throttle control Twist grip

Suzuki df2.5 Specifications

General

Starting System	Manual
Fuel Tank Capacity	1.0 L
Number of Cylinders	1
Full Throttle Operating Range	5250 - 5750 RPM
Steering	Tiller
Displacement	68 cm3 (4.2 cu.in.)
Max Output	2.5 hp
Weight	13.5 kg
Ignition System	CDI
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
