DF2.5 (Serial No. 410001 and later) 17
FUEL TANK AND FUEL COCK (For all markets except for US market)
OUTLINE
The related parts for fuel tank installation have been changed as follows.
•The fuel tank has been changed in shape.
•In accordance with this change, the fuel tank capacity have been changed.
FUEL TANK COMPONENTS
Fuel tank
Fuel tank bracket
Fuel tank spacer
Fuel tank bracket cushion

Suzuki df2.5 Specifications

General

Starting System	Manual
Fuel Tank Capacity	1.0 L
Number of Cylinders	1
Full Throttle Operating Range	5250 - 5750 RPM
Steering	Tiller
Displacement	68 cm3 (4.2 cu.in.)
Max Output	2.5 hp
Weight	13.5 kg
Ignition System	CDI
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
