Suzuki df2.5 Service Manual

12 DF2.5 (Serial No. 410001 and later)
THERMOSTAT
OUTLINE
The thermostat has been added as an service item of periodic maintenance.
The inspection procedure is as follows.
REMOVAL
For all markets except for US market
See the DF2.5 Service Manual, page 6-38.
For US market
1. Remove the recoil starter assembly. (See the DF2.5 Service
Manual, page 5-2.)
2. Remove the two bolts 1 securing fuel pump 2.
3. Remove the fuel pump 2.
4. Remove the two bolts 3 securing fuel pump bracket 4.
5. Remove the two bolts 6 and the thermostat cover 5.
6. Remove the thermostat 7.
Every 100 hours (12 months).

Suzuki df2.5 Specifications

General

Starting System	Manual
Fuel Tank Capacity	1.0 L
Number of Cylinders	1
Full Throttle Operating Range	5250 - 5750 RPM
Steering	Tiller
Displacement	68 cm3 (4.2 cu.in.)
Max Output	2.5 hp
Weight	13.5 kg
Ignition System	CDI
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
