DF2.5 (Serial No. 410001 and later) 1
CONTENTS
FOREWORD
This supplementary service manual describes the outline, technical data and servicing proce-
dures for the following models.
Please read and thoroughly familiarize yourself with this information before using it for your ser-
vice activities.
Applicable model and effective serial number:
00252F-410001 and later
NOTE:
•Use this supplement with the following service manuals:
DF2.5 Service Manual (P/no, 99500-97J01-01E)
DF2.5 Supplementary Service Manual (P/no, 99501-97J20-01E)
DF2.5 (Serial No. 410001 and later)
GENERAL INFORMATION .................................................................... 2
SPECIFICATIONS ........................................................................... 2
SERVICE DATA .............................................................................. 4
PERIODIC MAINTENANCE .................................................................. 10
PERIODIC MAINTENANCE SCHEDULE ...................................... 10
MAINTENANCE AND TUNE-UP PROCEDURES ................................ 11
IGNITION TIMING (For all markets except for US market) ........ 11
THERMOSTAT ............................................................................... 12
IGNITION AND ELECTRICAL .............................................................. 15
CARBURETOR (For all markets except for US market) ................... 16
REASSEMBLY ............................................................................... 16
FUEL TANK AND FUEL COCK
(For all markets except for US market) .............................................. 17

Suzuki df2.5 Specifications

General

Starting System	Manual
Fuel Tank Capacity	1.0 L
Number of Cylinders	1
Full Throttle Operating Range	5250 - 5750 RPM
Steering	Tiller
Displacement	68 cm3 (4.2 cu.in.)
Max Output	2.5 hp
Weight	13.5 kg
Ignition System	CDI
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
