DF2.5 “K8” (’08) MODEL 11
LOWER UNIT
WATER PUMP IMPELLER INSTALLATION
Before installing the impeller, apply Water Resistant grease to
the inner surface of impeller.
So that the impeller will not stick to the driveshaft.
N 99000-25160: SUZUKI WATER RESISTANT GREASE
PROPELLER SHAFT OIL SEAL PROTECTOR
A protector has newly been added to protect the propeller shaft
oil seal.
Oil seal protector

Suzuki df2.5 Specifications

General

Starting System	Manual
Fuel Tank Capacity	1.0 L
Number of Cylinders	1
Full Throttle Operating Range	5250 - 5750 RPM
Steering	Tiller
Displacement	68 cm3 (4.2 cu.in.)
Max Output	2.5 hp
Weight	13.5 kg
Ignition System	CDI
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
