Suzuki df2.5 Service Manual

DF2.5 (Serial No. 410001 and later) 15
IGNITION AND ELECTRICAL
OUTLINE
For all markets except for US market
The advance angle range of ignition timing has been changed
as follows.
Ignition timing: BTDC 10° at 2000 r/min – BTDC 31° at 4000 r/min
In accordance with this change, the igniter unit has been
changed.
NOTE:
Ignition timing for US market has not been changed as follows.
Ignition timing : BTDC 5° at 2000 r/min – BTDC 31° at 4000 r/min
For all markets
The advance angle range of ignition timing has been changed,
two timing marks of 5° and 10° have been added on flywheel
magneto.
5˚
10˚

Suzuki df2.5 Specifications

General

Starting System	Manual
Fuel Tank Capacity	1.0 L
Number of Cylinders	1
Full Throttle Operating Range	5250 - 5750 RPM
Steering	Tiller
Displacement	68 cm3 (4.2 cu.in.)
Max Output	2.5 hp
Weight	13.5 kg
Ignition System	CDI
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
