CHASSIS 6-15
Left
Right
Left
Right
Clearance
Spacer
WHEEL BEARING
• Apply grease to the wheel bearings.
W 99000-25030: SUZUKI SUPER GREASE “A”
• Install the wheel bearings as follows by using the special tools.
[ 09941-34513: Bearing/Steering race installer set
#
First install the left wheel bearing, then install the right
wheel bearing.
The sealed cover of the bearing must face outside.
BRAKE DISC
Make sure that the brake disc is clean and free of any greasy
matter.
• Apply THREAD LOCK SUPER “1360” to the disc mounting bolts
and tighten them to the specified torque.
! Brake disc bolt (Front): 23 N
.
m (2.3 kgf
.
m, 16.5 lb-ft)
J99000-32130: THREAD LOCK SUPER “1360”
To Next Page
