11-34 GSX-R750K2 (’02-MODEL)
REAR BRAKE HOSE ROUTING
After touching the brake hose union to the stopper, tighten the union bolt. After touching the br
ak
e hose
union to the stopper, tighten the union bolt.
Face the clamp ends backward.
Face the clamp ends forward.
Face the clamp ends forward.
The white paint faces to outside.
Stopper
Pass through the brake hose inside of the guide.
Stopper
14˚
21˚
After touching the brake hose union to the stopper, tighten the union bolt.
Stopper
