3-28 ENGINE
PISTON AND CONROD
• Push the conrod to upward and remove the piston and conrod
from the upper crankcase.
#
Be careful not to damage the cylinder wall by the
conrod.
• Remove the piston pin circlip.
• Separate the piston and conrod by driving out the piston pin.
NOTE:
Scribe the cylinder number on the head of the piston.
