9. Crankshaft / Crankcase / Transmission / Kick Starter

Mechanism Diagram ···················9-1

Precautions in Operation ···········9-3

Troubleshooting··························9-4

Crankcase Disassembly·············9-5

Crankshaft Inspection ················9-6

Transmission Disassembly······ 9-7

Transmission Inspection·········· 9-8

Kick Starter Disassembly········· 9-11

Crankcase Inspection··············· 9-11

Crankcase Assembly················ 9-12

Mechanism Diagram

Crankcase / Crankshaft

0.7~1.0kgf-m

0.8~1.2kgf-m

1.5~2.5kgf-m

Transmission
