2. Maintenance Information
Air Filter
2-6
Air filter element
Remove the right side cover.
Remove the air filter cover (5 Screws, 1 Bolt)
Remove the air filter element
Check the filter element for dirty or damaging.
Wash the air cleaner filter with high flash point
solvent (for example, kerosene or diesel)
Squeeze out the cleaning solvent thoroughly,
soak the element into gear oil, and squeeze
out the excessive.
Re-install the filter and the cover.
If the air cleaner filter element is too dirty or
damaged, please exchange with new parts.
Caution:
y Never use gasoline or other low-flash
point solvent for cleaning the element.
Throttle Operation
Operate the throttle grip to see if the throttle
cable is going smoothly.
If the throttle cable is deteriorated, twisted or
damaged, please exchange it.
If the cable is not going smoothly, apply some
lubrication oil onto it.
Measure the free play of the throttle grip,
through the inner side flange of it.
Free play：2~6 mm
Please loosen the lock nut and adjust the
throttle cable nut to reach the normal free play.
Screw×5
2~6 mm
Lock nut
Throttle cable nut
Air filter element
Bolt×1
