12. Rear Wheel / Rear Cushion / Swingarm
12-9
Drive chain / sprocket inspection
Driven sprocket
Check the condition of driven sprocket teeth.
Replace the sprocket if the teeth are worn out.
Caution
y Driven sprocket and drive chain condition
should be checked at the same time.
Drive chain
Clean and check the drive chain links
condition. Replace the drive chain if it is worn
out.
Driven sprocket / flange removal
Remove the rear wheel and drive chain.
Remove the rear flange locknut.
Remove the rear flange and sprocket.
Flat the sprocket bolt fixing washer.
Nut×1
Fixing washer
To Next Page
