8-4
OPTIONS
ATTACHMENT COMBINATION TABLE
The table below shows which bucket should be installed when the machine is using a
standard arm, middle arm or long arm. Select a proper bucket by following the table.
• Consult with Takeuchi before installing an optional attachment.
• Do not use any attachments not approved by Takeuchi. Doing so may cause safety
problems. Or, it may adversely affect the machine’s operation or service life.
• We will not be held responsible for any injuries, accidents or damage to its products
caused by the use by a non-approved attachment.
• The swing stopper must be installed when a bucket wider than a 640W (standard)
bucket is installed. Failure to do so may result in the bucket hitting the machine body.
√ :Can be used.
∆ :Can be used only for light operations (digging and loading of dry and loose soil or mud)
— :Cannot be used.
Total bucket mass = Bucket mass + Heaped bucket load (specific gravity: 1.8)
ATTACHMENT COMBINATION TABLE
Bucket
Rated capacity
m
3
(cu.yd.)
Bucket cutting
width
mm (inch)
Middle arm
1620 mm
(63.8 in.)
Long arm
1780 mm
(70.1 in.)
640 W (S.T.D.) 0.168 (0.2) 640 (25.2) √ √
T
otal bucket weight= Within 440 kg
(970 lb.)
Within 640 (25.2) √ √
To Next Page
