Monitoring Clos
ed Captioning (CC), Teletext, and Safe Area Compliance
Monitoring Closed Captioning and Teletext
To Configure Closed Captioning
and Teletext
Before using C losed Captions, configure
them in the C on figuration menu by
performing the following steps:
1. Press the CONFIG button to display the
Configuration menu.
2. Use the arrow k eys and SEL button to
make selections in the steps that follow.
3. Select Aux Data Settings.
4. Select C losed Caption Transport.
5. Select one of the CC stream types
or select AU
TO to search for closed
caption streams in the following order
and present the text of the first stream
type detec
ted:
For Compos
ite:
EIA-608 (VBI)
TeletextB VBI for Composite ( PAL)
For SD:
TeletextB
VBI for SD 625
EIA-608 (VBI)
EIA-608 (ANC)
EIA-608 (70
8)
EIA-708
TeletextB VBI
For HD:
EIA-608 (AN
C)
EIA-608 (708)
EIA-708
TeletextB VB
I
TeletextB OP47 SDP (ANC)
TeletextB OP47 Multi (ANC)
6. Define the alarms and settings for the
CC stream typ
e.
Waveform Rasterizers Quick Start User Manual 107
