Installation
International Power Plugs. Your instrument was shipped with one of the following power cord options. Power cords for
use in North Ame
rica are UL listed and CSA certified. Cords for use in areas other than North America are approved by at
least one authority acceptable in the country to which the product i s shipped.
Opt. A0 – North America power
Opt. A1 – Universal EUR power
Opt. A2 – United Kingdom power
Opt. A3 – Australia power
Opt. A5 – Switzerland power
Opt. A6 – Japan power
Opt. A10 – China power
Operating Considerations
Characteristic
Description
Input voltage
100 V to 240 V ±10%
Input power frequency
50 Hz to 60 Hz
Power consumption 100 W maximum, 50 W typical
Analog Audio Output power
capability
Capable of continuously driving a -10 dBFS sine wave into 600 Ω or -13 dB into
300 Ω.
Operating: +0 °C to +50 °C
Temperature
Nonoperating: -40 °C to +75 °C
Operating: 20% to 80% relative humidity (% R H) at up to +40 °C, non-condensing
Humidity
Nonoperating: 5% to 90% relative humidity (% RH) at up to +60 °C, non-condensing
Ventilation
The intake air vents in the front of the instrument must not be blocked and the rear
exhaust ve
nts requires at least 1 inch of clearance. No clearance is required above
or below the instrument.
Operating: 3,000 m (9,842 ft.)
Altitude
Nonoperating: 12,192 m (40,000 ft.)
Pollution
Degree
2, Indoor u
se only
2 Waveform Rasterizers Quick Start User Manual
