User’s Manual 2-1
Qosmio G30
Chapter 2
The Grand Tour
This chapter identifies the various components of your computer. Become
familiar with each component before you operate the computer.
Front with the display closed
Figure 2-1 shows the computer’s front with its display panel in the closed
position.
Figure 2-1 Front of the computer with display closed
Legal Footnote (Non-applicable Icons)*8
For more information on the Legal Footnote regarding Non-applicable
Icons, please refer to the Legal Footnotes section in Chapter 11. Click the
*8.
Display latch
System indicators
Wireless communication switch
Optical Disk Drive
Infrared receiver window
Optical Disk Drive The computer is configured with a DVD Super
Multi drive.
