TP-Link Touch P5 AC1900 User Manual

7Chapter 2 . Congure Touch P5 as a Router
2. 1 Connect Your Touch P5
Follow the steps below to connect your Touch P5.
1. Install the antennas and position them vertically.
Note: If your Internet connection is through an Ethernet cable from the wall, instead of a modem, connect the Ethernet
cable directly to your Touch P5’s Internet port, and skip step 2,3,4.
2. Turn off the modem, and remove the backup battery if it has one.
3. Connect the modem to the Internet port of your Touch P5 via an Ethernet cable.
4. Turn on the modem, and wait 2 minutes for it to restart.
5. Turn on your Touch P5 and wait until the system boot on the screen completes.
6. Connect your computer to your Touch P5.
Option 1: Wired
Connect your computer’s Ethernet port to the Ethernet port on your Touch P5 via the Ethernet cable.
Option 2: Wireless
Use the default SSID (Wireless Network Name) and Wireless Password printed on the product label at the bottom of your
Touch P5 to connect wirelessly.
Note: If you want to use your Touch P5 for media sharing, storage sharing and printer sharing, please connect the USB
storage device or printer to the USB port of your Touch P5.
Remote Access via
FTP Server
Local Storage
Sharing
Media Sharing
Printer Sharing

TP-Link Touch P5 AC1900 Specifications

General

Color	black
Frequency Band	2.4 ghz, 5.0 ghz
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac
Gigabit Ethernet Speed	yes
Antennas	3
Parental Control	yes
Firewall	other
Data Encryption	yes
Encryption Type	wep
Ports	rj-45
WAN Ports	1
Built In Modem	no
System Requirements	microsoft windows 98se, nt, 2000, xp, vista™ or windows 7, 8, 8.1, mac os, netware, unix or linux; internet explorer 11, firefox 12.0, chrome 20.0, safari 4.0, or other java-enabled browser

Weight and Dimensions

Height	2.1 inches
Width	11.2 inches
Net Weight	2.98 pounds
