TP-Link Touch P5 AC1900 User Manual

4Chapter 1 . Get to Know about Touch P5
Menu Screen
Tap the icons to perform various functions of your Touch P5, such as Quick Setup, Mode Selection, Parental Controls, etc.
1. 3. 2. The Back Panel
Your Touch P5’s back panel shows the connection ports, buttons and antennas. Refer to the following for detailed instructions.
Item Description
Power For connecting your Touch P5 to power socket via the provided power adapter.
Power On/Off
The switch for the power. Press it to power on or off your Touch P5.
USB 2.0
For connecting to a USB 2.0 storage device or a USB 2.0 printer.
USB 3.0
It’s on the right front corner of your Touch P5.
For connecting to a 3.0 USB storage device or a 3.0 USB printer. It is also compatible with USB 2.0 devices.
Internet
In router mode, it’s used for connecting to the DSL/cable Modem or Internet.
In repeater mode, it’s used for connecting to Ethernet-enabled device, working the same as the Ethernet port.
In access point mode, it’s used for connecting to front router or Internet.
Ethernet (1, 2, 3, 4)
These ports (1, 2, 3, 4) connect your Touch P5 to the local computer(s).
Reset
With your Touch P5 powered on, use a pin to press and hold the Reset button until the Touch P5 logo displays.
Antennas
Used for wireless operation and data transmit. Upright them for the best Wi-Fi performance.

TP-Link Touch P5 AC1900 Specifications

General

Color	black
Frequency Band	2.4 ghz, 5.0 ghz
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac
Gigabit Ethernet Speed	yes
Antennas	3
Parental Control	yes
Firewall	other
Data Encryption	yes
Encryption Type	wep
Ports	rj-45
WAN Ports	1
Built In Modem	no
System Requirements	microsoft windows 98se, nt, 2000, xp, vista™ or windows 7, 8, 8.1, mac os, netware, unix or linux; internet explorer 11, firefox 12.0, chrome 20.0, safari 4.0, or other java-enabled browser

Weight and Dimensions

Height	2.1 inches
Width	11.2 inches
Net Weight	2.98 pounds
