TP-Link Touch P5 AC1900 User Manual

97Chapter 4 . Congure Touch P5 as an Access Point
4. 8 LAN
By default, your Touch P5 is set to obtain an IP address automatically from the host network. The LAN app allows you to use a
specific IP address appropriate to your network demand.
Note: We do NOT recommend you change the IP address unless you are quite sure about the IP setting for special network
demand. Random changes may lead to Internet disconnection.
1. On the menu screen, tap the LAN icon to open it.
2. Tap Type to select Use the following IP address and tap Done.
3. Tap IP Address to enter an IP address in dotted decimal notation. It should be in the same subnet as the host network.
4. Tap Subnet Mask to enter the subnet mask in dotted decimal notation. It determines the network portion and host
portion of the IP address.
5. Tap Default Gateway to enter the gateway in dotted decimal notation . It should be in the same subnet as the IP address.
6. Tap Save.

TP-Link Touch P5 AC1900 Specifications

General

Color	black
Frequency Band	2.4 ghz, 5.0 ghz
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac
Gigabit Ethernet Speed	yes
Antennas	3
Parental Control	yes
Firewall	other
Data Encryption	yes
Encryption Type	wep
Ports	rj-45
WAN Ports	1
Built In Modem	no
System Requirements	microsoft windows 98se, nt, 2000, xp, vista™ or windows 7, 8, 8.1, mac os, netware, unix or linux; internet explorer 11, firefox 12.0, chrome 20.0, safari 4.0, or other java-enabled browser

Weight and Dimensions

Height	2.1 inches
Width	11.2 inches
Net Weight	2.98 pounds
