78 CLCH-SVX07C-EN
Component Installation Requirements
Other Connections
Access, filter, and other sections may have open inlets with a 2-inch (sizes 3-120) panel frame for
connecting the ductwork. If the duct is lined, it is important the insulation does not obstruct the
opening of the section.
Figure 68. External face-and-bypass with duct configuration designed to bypass air into a
horizontal fan section
Fan
Coil Coil
External
Face and Bypass
Duct
Figure 69. Typical duct flat/flange end of unit connection -
uninsulated
Figure 70. Typical duct flat/flange end of unit connection -
insulated
Unit Section
End of unit
2-inch panel
Thermal
break
Uninsulated Duct
2-inch panel
Thermal
break
Airflow
Unit Section
End of unit
2-inch panel
Thermal
break
Internally insulated Duct
2-inch panel
Thermal
break
Airflow
