3-92 OM 25-3503 us – Edition 4.1 * * 2503_3503b340.fm
Operation
3.53 Hydraulic quickhitch (option)
• Attend specific training before putting into operation. Training must be given by
authorized technical personnel and must be understood by the operator.
• For safety reasons, the quickhitch must be operated with two control elements. This
avoids opening the quickhitch unintentionally during work operation.
• Both hitch claws must be clean before hitching.
• For more information, see Easy Lock/Powertilt with Easy Lock Operator’s Manual.
• Store the Operator’s Manual of the hydraulic quickhitch together with the Operator’s
Manual of the machine.
Crushing hazard when picking up attachments!
If an attachment is not locked correctly, it can come off and cause serious
injury or death.
☞ Do not allow anyone to stay in the danger zone.
☞ Do not use damaged attachments.
☞ Check pin F must be fully retracted. Otherwise repeat the lock cycle until
check pin F is retracted.
☞ Ensure safe locking with a rapid succession of stick and bucket movements
as close as possible to the ground.
☞ Operate the machine only with a safely locked attachment.
Crushing hazard when attachments are removed!
If an attachment is not locked correctly, it can tip over and cause serious injury
or death.
☞ Do not allow anyone to stay in the danger zone.
☞ Lower the attachment to level and firm ground ensuring stability.
Injury hazard due to incorrect operation of the hydraulic quickhitch!
For system-specific reasons, the quickhitch can also be operated with other
hydraulic functions. This can cause serious injury or death
☞ Operate the hydraulic quickhitch only with the function Raise stabilizer
blade.
