Introduction
1.9 Other signs and symbols (up to AG01597)
The following states signs and symbols which are not unequivocally comprehensible. They
do not contain explanatory text and are not explained in the following chapters.
Meaning
Machine is raised by the lifting eyes
– see chapter 3.38 Crane lifting the machine on page 3-60
Location
On either side of the stabilizer blade, and on either side of the boom.
Meaning
Indicates the tie-down points for tying down the machine.
The mounting points are used for tying down the machine during loading and transporta-
tion.
– see chapter 3.40 Tying down the machine on page 3-63
Location
On either side of the stabilizer blade, and on either side of the undercarriage.
Meaning
Noise levels produced by the machine.
L
WA
= sound power level
Other information – see chapter 6.5 Noise levels on page 6-6
Location
Next to the cabin door
Meaning
This label shows the forward travel direction.
Location
On either side of the undercarriage
Meaning
General indication of danger
This label warns persons standing or working near the excavator of an existing danger
within the area of increased danger around the machine.
Location
On either side of the boom
Meaning
The CE mark means that the machine meets the requirements of the Machine Directive
and that the conformity procedure has been performed. The machine meets all the health
and safety requirements of the Machine Directive.
Location
On the type label
Fig. 8: Lifting eyes
Fig. 9: Tie-down points for tying down the machine
Fig. 10: Noise level indication
93
Fig. 11: Direction indicator
Fig. 12: Danger label
Fig. 13: CE mark
