Operation
3.1 Cabin overview
Pos. Description For more information see page
1 Control lever (left) ..............................................................................................................................................................3-72
2 Control lever (right) ............................................................................................................................................................3-77
3 Control lever base (left)
4 Control lever base (right)
5 Armrest (left)
6 Armrest on the right (not shown)
7 Lever (horizontal seat adjustment).......................................................................................................................................3-4
8 Air vents...............................................................................................................................................................................3-4
9 Radio (option)
10 Operator seat (backrest adjustment) ...................................................................................................................................3-4
11 Seat belt (lock).....................................................................................................................................................................3-4
12 Cup holder
13 Document storage (underneath the seat console)
14 Switch panel (right) ..............................................................................................................................................................3-4
15 Switch panel (left)
1
...............................................................................................................................................................3-4
1. Cabin top view up to serial no. AG02452: automatic engine speed setting (from serial no. AG00580) or hydraulic quickhitch (from serial no. AG02027)
16 Throttle...............................................................................................................................................................................3-11
17 Stabilizer-blade lever ...........................................................................................................................................................3-4
18 Auxiliary hydraulics pedal ....................................................................................................................................................3-4
19 Preheating start switch.......................................................................................................................................................3-11
20 12 V power outlet
2
2. Power outlet for cabin version/12 V connection for canopy version: from 1st quarter of 2015 / WNxxxxxxxxxxxxxxxxx (2503); WNxxxxxxxxxxxxxxxxx (3503)
21 Display element ...................................................................................................................................................................3-7
22 Accelerator pedal (left).........................................................................................................................................................3-4
23 Accelerator pedal (right).......................................................................................................................................................3-4
24 Drive lever (left)....................................................................................................................................................................3-4
25 Drive lever (right) .................................................................................................................................................................3-4
26 Immobilizer status indicator (option) ..................................................................................................................................3-23
27 Immobilizer emitter/receiver unit........................................................................................................................................3-23
28 Changeover valve for SAE/ISO controls (option, underneath the base plate)...................................................................3-77
29 Weight adjustment for seat ................................................................................................................................................3-51
30 Proportional controls indicator (option)..............................................................................................................................3-80
31 Lever for engine and valve cover.......................................................................................................................................3-58
32 Hydraulic quickhitch pedal (option) ...................................................................................................................................3-92
33 VDS button (upper carriage tilting – option 3503)
3
............................................................................................................3-87
3. VDS operation with console switch from serial no. AG02695
