Operation
3.7 Display element 3503 Tier IV
The display element and the multifunctional display informs the operator of the operating
states, required maintenance or possible machine malfunctions.
Information!
After switching on the starter, the indicator lights are checked during the first 2
seconds and the current reading of the maintenance meter is displayed. Then
the operating hours are automatically displayed.
5
8
4
9
1
6
2
3
7
10
11
12
16
13
14
15
17 18
Switch panel (right)
Switch panel (left)
19
20 21
22
23
24
25
26
27 28
