6-10 OM 25-3503 us – Edition 4.1 * * 2503_3503b610.fm
Technical datac
6.8 Powertilt (option 3503)
6.9 Weights
Information!
The actual machine weight depends on the selected options and must be read off
the type label.
Add the weight of all subsequently installed equipment to the weight of the
machine.
Weight indications can vary by +/Ã 2%.
Powertilt Model 3503
Model size 6
Piston stroke 525 cm³ (32 in³)
Required oil flow 3 – 6 l/min (0.8 – 1.6 gal/min)
Connections 1/4 in
Swiveling range 180°
Weight 65 kg (143.3 lbs)
Drive torque – at 210 bar (3045 psi) 2990 Nm (2,205 ft.lbs)
Holding torque – at 225 bar (3263 psi) 7270 Nm (5,362 ft.lbs)
Minimum hose/pipe size
Connecting hose size
10 mm (0.4 in)
6 mm (0.25 in)
Type
Transport weight
1
kg (lbs)
1. Transport weight: basic machine + 10 % fuel capacity
Operating weight
2
kg (lbs)
2. Operating weight: basic machine + full fuel tank + backhoe bucket (400 mm) + user (75 kg/165 lbs)
2503 canopy 2483 (5,474) 2639 (5,818)
2503 cabin 2592 (5,714) 2747 (6,056)
3503 canopy 3424 (7,549) 3602 (7,941)
3503 cabin 3551 (7,829) 3728 (8,219)
3503 VDS canopy 3689 (8131) 3866 (8,523
3503 VDS cabin 3815 (8,411) 3993 (8,803)
3503 Vario canopy 3699 (8,155) 3877 (8,547)
3503 Vario cabin 3826 (8,435) 4003 (8,825)
