Wacker Neuson 3503 User Manual

OM 25-3503 us – Edition 4.1 * 2503_3503b530.fm 5-35
Maintenance
5.16 Fluids and lubricants
Component/application Fluid/lubricant Specification
Season/tempera-
ture
Capacities
1
1. The capacities indicated are approximate values; the oil level check alone is relevant for the correct oil level
Capacities indicated are no system fills
Diesel engine Tier III Engine oil SAE 10W-40
API: CF, CF-4, CI-4
í20 °C (í4 °F)
+40 °C (104 °F)
About 3.4 l (0.9
gal)
ACEA: E3, E4, E5
JASO: DH-1
Diesel engine Tier IV Engine oil SAE 10W-40
API: CJ-4
í20 °C (í4 °F)
+40 °C (104 °F)
About 10.6 l (2.8
gal)
ACEA: E9
ECF-3
Traveling drive
Gearbox oil SAE 80W-
90
API: GL-4, GL-5 Year-round
About 0.6 l each
(0.2 gal)
Hydraulic oil reservoir
Hydraulic oil EUROLUB HVLP46
2
2. According to DIN 51524 section 3
Year-round
3
3. Depending on local conditions – see Hydraulics oil grade on page 5-37
2503: 27 l (7 gal)
3503: 50 l (13 gal)
Biodegradable oil
4
4. Biodegradable hydraulic oil based on saturated synthetic esters with an iodine value of < 10, according to DIN 51524, section 3, HVLP, HEES
PANOLIN HLP Synth 46
BP BIOHYD SE-S 46
Roller and friction bearings
Grease KF2K-20
5
5. SKPF2K-20 lithium-saponified grease according to DIN 51502/ISO 6743-9
Year-round As required
Live ring: ball bearings
Live ring gears
Grease zerks
Battery terminals Acid-proof grease
6
6. Standard acid-proof grease
FINA Marson L2 Year-round As required
Fuel tank Diesel fuel
7
7. In countries without regulations on exhaust gas emissions, diesel fuel with a sulfur content of up to 4000 ppm (0.4 %) can be used.
2-D ASTM D975 – 94 (USA)
7,8
8. Sulfur content up to 15 ppm (0.0015 %)
Depending on
outside tempera-
ture
Summer or winter
diesel fuel
2503: 41 l (11 gal)
3503: 52 l (14 gal)
1-D ASTM D975 – 94 (USA)
EN 590 : 96 (EU)
7,9
9. Sulfur content up to 10 ppm (0.001 %)
ISO 8217 DMX (International)
BS 2869 – A1 (GB)
BS 2869 – A2 (GB)
7,8
JIS K2204 (Japan)
KSM-2610 (Korea)
GB252 (China)
Radiator Coolant
Distilled water + antifreeze ASTM
D4985 (reddish)
10
10. 2503: up to serial no. WNCE0304PPAL00399; 3503: up to serial no. WNCE0307APAL00999
Year-round
About 4.5 l (1.2
gal)
Distilled water + antifreeze ASTM
D6210 (violet)
11
11. 2503: from serial no. WNCE0304HPAL00400; 3503: from serial no. WNCE0307PPAL01000
Washer system Cleaning solution Water + antifreeze Year-round 1.2 l (0.3 gal)
