Technical data
Fuses behind the right-hand trim
Relays behind the right-hand trim
F2
F3
F1
Fig. 222: Fuses (up to serial number
WNCE0801CPAL0050)
Fuse no. Rated current (A) Protected circuit
F1 40 A
Main fuse: air-pressure sensor/output adap-
tation (Yanmar 3TNV74F-SNNS)
F2 10 A Fuse: relay, indicator, cutoff solenoid
F3 10 A
Fuse: horn, working light 12 V power outlet
(up to serial number WNCE0801CPAL0050),
travel signal (option)
F4 10 A
12 V power outlet (from serial number
WNCE0801TPAL0051)
Fig. 223: Fuses (from serial number WNCE0801TPAL0051)
F2
F3
F1
F4
Fig. 224: Relays
K8
K9
K7
Relay no. Protected circuit
K 7 Starting relay
K 8 Cutoff solenoid time lag relay 1s
K 9 Cutoff solenoid switching relay
