OM 803 us – Edition 3.7 * 803b610.fm 6-9
Technical data
6.10 Coolant compound table
6.11 Weight
The actual machine weight depends on the selected options and must be read off the
type label.
Add the weight of all subsequently installed equipment to the weight of the machine.
Weight indications can vary by +/− 2%.
Outside temperature
1
1. Use the 1:1 concentration for warm outside temperatures, too, to ensure protection against corrosion, cavitation and deposits.
Water Coolant
2
2. Do not mix the coolant with other coolants.
Up to °C (°F) % by volume % by volume
−37 (−34.6) 50 50
803 without rollbar
Operating weight
1
1. Operating weight: basic machine + full fuel tank + backhoe bucket (250 mm/10 in) + operator (75 kg/165 lbs).
1032 kg (2,275 lbs)
Transport weight
2
2. Transport weight: basic machine + 10 % fuel capacity.
935 kg (2,061 lbs)
803 with rollbar
Operating weight
1
1087 kg (2,396 lbs)
Transport weight
2
990 kg (2,182 lbs)
