OM 803 us – Edition 3.7 * 803b330.fm 3-33
Operation
Replace the lock nuts every time they are loosened.
Raising the rollbar
☞Stop the machine on firm, level and horizontal ground
☞Stop the engine
☞Raise the lock lever
☞Remove the starting key
In order to raise it, the rollbar must be held by one person on either side.
☞Remove the lock nuts and screws A on either side
☞Slowly and carefully raise the rollbar
☞Insert the screws again on either side and secure them with the lock nuts
Replace the lock nuts every time they are loosened.
Lowering the rollbar
☞Stop the machine on firm, level and horizontal ground
☞Stop the engine
☞Raise the lock lever
☞Remove the starting key
In order to lower it, the rollbar must be held by one person on either side.
☞Remove the split pins and pins B on either side
☞Slowly and carefully lower the rollbar toward C to the limit S.
Raising the rollbar
☞Stop the machine on firm, level and horizontal ground
☞Stop the engine
☞Raise the lock lever
☞Remove the starting key
In order to raise it, the rollbar must be held by one person on either side.
☞Slowly and carefully raise the rollbar
☞Fit pins B again on either side and secure them with the split pins
