OM 803 us – Edition 3.7 * 803b320.fm 3-9
Operation
Operation checklist
After starting the engine, check and observe the following points:
“Parking” checklist
Check and observe the following points when parking the machine:
No. Question ✔
1 Indicator light for engine and coolant temperature gone out? (➠ 3-6)
2
Indicator lights for engine oil pressure and alternator charge function gone
out? (➠ 3-11)
3 Do the travel levers and pedals work correctly? (➠ 3-16)
4 Telescopic travel gear extended? (➠ 3-24)
No. Question ✔
1 Attachments lowered to the ground? (➠ 3-26)
2 Stabilizer blade lowered to the ground?
3 Lock lever raised, especially if the machine cannot be supervised? (➠ 3-62)
4 Machine keys removed, especially if the machine cannot be supervised? (➠ 3-26)
When parking on public roads:
5 Machine adequately secured?
When parking on slopes:
6
Machine also secured with chocks under the tracks to prevent it from rolling
away? (➠ 3-26)
