Welch Allyn 53 Service Manual

Overview Product Configurations
Vital Signs Monitor Series 300 13 Service Manual
Product Configurations
Model numbers for the configurations are as follows:
Recommended Service Intervals
Model
Number
Monitoring Parameters Serial
Number
Prefix
53000 NIBP
5300P NIBP, Printer
530T0 NIBP, Temperature
530TP NIBP, Temperature, Printer JA
53N00 NIBP, SpO
2
53N0P NIBP, SpO
2
, Printer
53NT0 NIBP, SpO
2
, Temperature
53NTP NIBP, SpO
2
, Temperature, Printer
Interval or Condition Action Recommended Procedure Page
Every 6 - 24 months
(per hospital protocols)
Complete functional test Functional Verification 17
Battery does not hold a
charge
Check battery capacity
Replace battery
Functional Verification
Disassembly Procedure
17
43
Monitor has been dropped
or otherwise damaged
Complete functional test Functional Verification 17
Monitor malfunctioning Complete functional test Functional Verification 17
Monitor does not pass
Functional Verification
Troubleshooting and repair
followed by functional test
Return to authorized service
center
Troubleshooting and Repair
Disassembly Procedure
Functional Verification
37
43
17
