Disassemble and Remove the NIBP Assembly Disassembly Procedure
Service Manual 58 Vital Signs Monitor Series 300
...and the flanged side down.
Disassemble and Remove the NIBP Assembly
1. Remove the tubing and the pump.
Repair or replacement of the NIBP assembly is not supported. All NIBP
service must be performed at an authorized Welch Allyn service center.
J3 cable connector properly
aligned with the J3
connector on the main
board. The cable connector
is slotted on the top side.
J3 cable connector properly
aligned with the J3
connector on the main
board. The cable connector
has latching tabs on the
bottom side.
