Welch Allyn Monitor Service Utility Troubleshooting and Repair
Service Manual 40 Vital Signs Monitor Series 300
Welch Allyn Monitor Service Utility
Monitor Software Utility Introduction
The Welch Allyn Monitor Service Utility (840-0676-XX) is a software tool that provides the
following end-user service functions:
• Download, save, and print monitor event log files.
• Characterize NIBP. Characterization sets the NIBP module for specific system
pneumatic volume, and is required after replacement of any NIBP component (pump,
tubing, air filter, check valve, or circuit-board assembly).
Monitor Software Utility Installation
To install the Welch Allyn Monitor Service Utility on a PC, insert the CD into the CD drive.
• If Autostart is enabled on the PC, the installation program starts automatically.
• If Autostart is not enabled on the PC, manually start the installation program as
follows:
Start > Run N:\Setup.exe
(where N: is your CD drive)
Monitor Software Utility Setup
1. Install the cable between the serial port on your PC and the RS232 port on the
monitor.
2. Connect the power adapter to the monitor.
3. Turn on the monitor.
Characterization does not support the replacement of any
components—including transducers—of the NIBP module. Do not
attempt repair of the NIBP module; it must be replaced as an
assembly.
The Welch Allyn Monitor Service Utility requires the serial cable/DB9F
adapter 008-0842-XX or equivalent.
