Disassemble the Front Chassis Assembly Disassembly Procedure
Service Manual 50 Vital Signs Monitor Series 300
Disassemble the Front Chassis Assembly
The front chassis assembly contains the display board, keypad, and NIBP air fitting.
1. Remove the five screws securing the display board.
Ferrite bead on
the rear chassis
Ferrite bead on
the rear chassis
Display-board flex
cable (to J5 on
the main board)
Temperature-board flex
cable (to J12 on
the main board)
