Procedures Overview Disassembly Procedure
Service Manual 44 Vital Signs Monitor Series 300
Connectors
Connector Types
The procedures described below require you to disconnect and reconnect ZIF (zero-insertion
force) connectors, squeeze-release connectors, and pressure connectors.
Zero-insertion force (ZIF) Flex-cable Connectors
ZIF flex-cable connectors include J1 on the display board, CN2 on the printer board, J? on the
temperature board, and J5 and J12 on the main board.
ZIF connectors use a sliding outer piece that latches and unlatches to secure and release the
flex cable.
• To release a ZIF cable, slide the latching piece of the connector away from the
connector body and toward the cable; the cable can then be removed without effort.
• To connect a ZIF cable, slide the latching piece of the connector body and toward the
cable, insert the flex cable easily into the connector, and slide the latching piece back
toward the connector body until it clicks into place.
Side-release Connectors
Side-release connectors include J7 and J9 on the main board, J2 on the SpO
2
board, and J? on
the temperature board.
To use side-release connectors, squeeze the sides of the connectors to insert or remove the
cables.
Pressure Connectors
Pressure connectors include and CN1 and CN3 on the printer board and J2, J3, J4, J6, J8, J10,
and J11 on the main board.
To use pressure connectors, grasp each mating connector half and pull the halves apart or
insert one half into the other.
Caution All connectors are keyed or coded to facilitate proper connection.
Take care to correctly align all connector halves before attempting to connect
them.
Caution Do not attempt to remove a flex cable until the ZIF latch has been
opened.
Caution Never attempt to disconnect cables by pulling on the wires. Always
disconnect cables by grasping and pulling only on the connector halves.
