Equipment Required Functional Verification
Service Manual 18 Vital Signs Monitor Series 300
Equipment Required
The following equipment is required for functional verification of a fully configured monitor.
Commercially Available General-purpose/Medical Test Equipment
Item Manufacturer Part Number/Specification
Power supply Variable, 0-8 VDC, 0.75A (minimum), with
voltage and current indicators (for 1mA current
measurement)
Digital pressure meter Netech Digimano 1000 or equivalent
AC withstand voltage (hi-pot) tester Associated Research 3605 or equivalent
SpO
2
functional tester
(for testing the monitor only)
Nellcor SRC-MAX
SpO
2
extension cable (required for SRC-MAX) Nellcor DEC-8
SpO
2
simulator
(for testing the monitor and the SpO
2
sensor)
Fluke (Biotek) Index2 XL/XLFE or equivalent
Syringe, 60 mL, Slip tip, Luer BD (Becton, Dickinson) 309654 or equivalent
Hi-pot cable connectors See page 34.
Timer
Welch Allyn Accessories and Test Equipment
Temperature test key
(for testing the monitor only)
06138-000
9600 Temperature calibration tester
(for testing the monitor and the temperature probe)
01800-210, 110V
01800-500, 220V
01800-810, 220V UK
01800-910, 220V Australia
Neonatal cuff hose, 96” 008-0265-XX
Neonatal #1 cuff, disposable, box of 10 008-0620-XX
500 cc air volume T112854
DC power adapter 5200-101A
Battery substitution connector
(Use the female end from the cable set)
660-0237-XX
Welch Allyn Monitor Service Utility
(required for NIBP repair or replacement;
not required for functional testing)
840-0676-XX
Service Serial Cable (for use with the Welch Allyn
Monitor Service Utility 840-0676-XX)
008-0842-XX
NIBP tubing connector, threaded 600-0021-XX
tubing, 1’ 600-0179-XX
Tee, plastic 600-0043-XX
