L3130 · L3430 · L3830 · L4630 · L5030, WSM
SPECIFICATIONS
SPECIFICATIONS
ROPS Type
Note : * Manufacture’s estimate
The company reserves the right to change the specifications without notice.
W10281170
Model
L3130 L3430
Manual Transmission
Engine
Model D1503-MA-E-GST-EU D1703-MA-E-GST-EU
Type Indirect injection vertical, water-cooled, 4-cycle diesel
Number of cylinders 3
Total displacement 1.499 L (91.5 cu.in.) 1.647 L (100.5 cu.in.)
Bore and stroke 83 × 92.4 mm (3.3 × 3.6 in.) 87 × 92.4 mm (3.4 × 3.6 in.)
Net power 23.1 kW (31.0 HP)* 25.1 kW (33.6 HP)*
PTO power
(factory observe)
19.0 kW (25.8 HP)* / 2700 min
−1
(rpm) 21.3 kW (29.0 HP)* / 2700 min
−1
(rpm)
Maximum torque 102.9 N·m (10.5 kgf·m, 75.9 ft-lbs) 108.3 N·m (11.05 kgf·m, 79.9 ft-lbs)
Battery capacity 12 V, RC : 123 min, CCA : 490 A
Fuel Diesel fuel No. 1 [below −10 °C (14 °F], Diesel fuel No. 2-D [above −10 °C (14 °F)]
Capacities
Fuel tank 40 L (10.6 U.S.gals, 8.8 Imp.gals)
Engine crankcase
(with filter)
5.7 L (6.0 U.S.qts, 5.0 Imp.qts)
Engine coolant 6.0 L (6.3 U.S.qts, 5.3 Imp.qts)
Transmission case 42 L (11.1 U.S.gals, 9.2 Imp.gals)
Dimensions
Overall length
(without 3P)
3025 mm (119.1 in.) 3015 mm (118.7 in.)
Overall width (min. tread) 1430 mm (56.3 in.)
Overall height
(with ROPS)
2255 mm (88.8 in.) 2415 mm (95.1 in.)
Wheel base 1805 mm (71.1 in.)
Min. ground clearance 370 mm (14.6 in.)
Tread
Front 1150 mm (45.3 in.)
Rear 1110 mm (43.7 in.), 1205 mm (47.4 in.), 1300 mm (51.2 in.), 1385 mm (54.5 in.)
Weight (with ROPS) 1480 kg (3265 lbs) 1460 kg (3220 lbs)
Travelling
system
Standard
tire size
Front 7-16
Rear 12.4-24
Clutch Dry type single stage
Steering Hydrostatic power steering
Transmission
F8, R8 fully synchronized main and shuttle transmission
(with creep speed model : F16, R16 fully synchronized main and shuttle transmission)
Braking system Wet disk type
Min. turning radius
(with brake)
2.7 m (8.9 feet)
Hydraulic
system
Hydraulic control system Position control
Pump capacity 31.5 L (8.3 U.S.gals, 6.9 Imp.gals) / min.
Three point hitch SAE Category 1
Max. lift
force
At lift points 1700 kg (3750 lbs)
24 in. behind
lift points
1200 kg (2650 lbs)
System pressure 17.7 MPa (180 kgf/cm
2
, 2560 psi)
PTO
Rear PTO SAE 1-3/8, 6 splines
PTO / Engine speed 540 min
−1
(rpm) / 2550 min
−1
(rpm), 750 min
−1
(rpm) / 2250 min
−1
(rpm)
KiSC issued 02, 2007 A
