wsm L503 - 2 Servicing Specifications

9-S8
L3130 · L3430 · L3830 · L4630 · L5030, WSM
ELECTRICAL SYSTEM
2. SERVICING SPECIFICATIONS
W10138740
Item Factory Specification Allowable Limit
Starter
Commutator
Mica
Brush
Brush Holder and Holder Support
O.D.
Under Cut
Length
Resistance
30.0 mm
1.181 in.
0.50 to 0.80 mm
0.0197 to 0.0315 in.
15.0 mm
0.591 in.
Infinity
29.0 mm
1.142 in.
0.20 mm
0.0079 in.
11.0 mm
0.433 in.
–
Glow Plug Resistance Approx. 0.9 Ω –
Fuel Level Sensor
Float at Upper-most Position
Float at Lower-most Position
Resistance
Resistance
1.0 to 5.0 Ω
103 to 117 Ω
–
–
Coolant Temperature Sensor
at 130 °C (266 °F)
at 105 °C (221 °F)
at 80 °C (176 °F)
at 50 °C (122 °F)
Resistance
Resistance
Resistance
Resistance
Approx. 12.2 Ω
Approx. 23.6 Ω
Approx. 51.9 Ω
Approx. 153.9 Ω
–
–
–
–
Alternator
Stator
Rotor
Slip Ring
Brush
No-load voltage
Resistance
Resistance
O.D.
Length
More than 14 V
Less than 1.0 Ω
2.9 Ω
14.4 mm
0.567 in.
10.5 mm
0.413 in.
–
–
–
12.8 mm
0.504 in.
8.4 mm
0.331 in.
GST Proportional Reducint Valve Resistance Approx. 8 to 9 Ω –
Shift Solenoid Valve Resistance Approx. 11 to 15 Ω –
