3-S1

L3130 · L3430 · L3830 · L4630 · L5030, WSM

TRANSMISSION

1. TROUBLESHOOTING

[1] GENERAL

W1014322

Symptom Probable Cause Solution

Reference

Page

Excessive

Transmission Noise

• Transmission fluid insufficient

• Gear worn or backlash improper

• Bearing worn or broken

• Shift fork worn

• Spline worn

• Snap rings on the shaft come off

• Spiral bevel pinion lock nut improperly

tightened

• Improper backlash between spiral bevel

pinion and spiral bevel gear

• Improper backlash between differential pinion

and differential side gear

Replenish

Replace

Repair or replace

Tighten

Adjust

G-7, 8

3-S46 to

S48

3-S43

–

3-S36

3-S46

3-S47

Gear Slip Out of

Mesh

• Shift linkages rusted

• Shifter or shift fork worn or damaged

• Shift fork interlock ball spring weaken or

damaged

• Interlock ball fallen

• Synchronizer unit damaged

• Gears worn or broken

Repair

Replace

Reassemble

Replace

–

3-S27, S63

3-S44

–

Hard Shifting • Shifter or shift fork worn or damaged

• Shift fork bent

• Shift linkage rusted

• Shaft part of shift arms rusted

• Synchronizer unit damaged

Replace

Repair

Replace

–

3-S44

Gears Clash When

Shifting

• Clutch does not release

• Gears worn or damaged

• Synchronizer unit damaged

Adjust or repair

Replace

G-24

–

3-S44

Differential Lock Can

Not Be Set

• Differential lock shift fork damaged

• Differential lock shift fork mounting clevis pin

damaged

• Differential lock shifter pin bent or damaged

• Differential lock fork shaft bent or damaged

Replace

3-S39

Differential Lock

Pedal Does Not

Return

• Differential lock pedal return spring weaken

or damaged

• Differential lock shifter pin bent or damaged

• Differential lock fork shaft bent

Replace

–

3-S39

Excessive or

Unusual at All Time

• Improper backlash between spiral bevel

pinion and spiral bevel gear

• Improper backlash between differential pinion

and differential side gear

• Bearings worn

• Insufficient or improper type of transmission

fluid used

Adjust

Replace

Replenish or replace

3-S46

3-S47

–

G-7, 8

Noise While Turning • Differential pinion or differential side gears

worn or damaged

• Differential lock binding (does not disengage)

• Bearing worn

Replace

3-S42

3-S39

–

KiSC issued 02, 2007 A
