Phaser 6280 Color Laser Printer Service Manual 3-25
Error Messages and Codes
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Feeder Assy., PL3.2.1
■ Actuator B, PL3.2.15
■ Regi Clutch, PL3.2.23
■ Registration Sensor, PL3.2.30
■ Regi Sensor Harness, PL3.2.37
■ MCU Board, PL9.1.20
■ Right Side Harness, PL10.1.15
■ “Map 2 - Laser Unit, Feeder Assembly”
on page 10-10
■ “Map 3 - Image Processor Board and
Dispenser” on page 10-11
■ “Map 4 - LVPS and MCU Boards” on
page 10-12
■ “Tray 1 (MPT) and Registration” on
page 10-23
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1. Check the paper condition.
2.Is the paper damaged?
Replace the
paper.
Go to step 2.
Complete.
2 1. Check the Regi Rolls for correct
installation.
2.Is the Regi Metal Roll pressed
against the Regi Roll Assembly by
spring pressure?
Go to step 3. Replace the
Feeder
Assembly
(
page 8-36).
3 1. Perform the Regi Clutch test
(page 4-51): Service Mode >
Engine Diag > Motor Test > Regi
Clutch.
2.Does the Clutch operate properly?
Go to step 4. Replace the
Regi Clutch
(
page 8-40).
4 1.Perform the Regi Sensor test
(page 4-30): Service Mode >
Engine Diag > Sensor Test > Regi
Sensor.
2.Does the number increase by 1
when the Actuator is activated?
Replace the
MCU Board
(
page 8-86).
Go to step 5.
5 1. Check the Actuator B for damage.
2.Is the Actuator B damaged?
Replace the
Feeder
Assembly
(
page 8-36).
Go to step 6.
6 1. Check the wiring harness
connectors P/J29, P/J292, and P/
J2922 between the MCU Board and
the Regi Sensor.
2.Are the connectors securely
connected?
Go to step 7. Reconnect the
connectors.
