Phaser 6280 Color Laser Printer Service Manual 3-53
Error Messages and Codes
Replace Fuser
The Fuser has reached its end of life.
Warning
The Fuser may be hot. Turn the printer power Off and allow at least 5
minutes for the Fuser to cool before removing the Fuser.
Applicable Chain Link
Chain Link 010-351: IOT Fuser Life Over
Initial Action
Check the Fuser life using CentreWare IS.
Cycle printer power.
If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
Fuser, PL6.1.10
MCU Board, PL9.1.20
“Map 1 - Electrical and Drive” on
page 10-9
“Map 4 - LVPS and MCU Boards” on
page 10-12
“Fuser” on page 10-35
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1. Check the Fuser life using CentreWare IS.
2.Does the Level show 0%?
Replace the
Fuser
(
page 8-11).
Go to step 2.
2 Is the Fuser correctly installed? Go to step 3. Reseat the
Fuser
(
page 8-11).
3 Does the error still occur? Go to step 4. Complete.
4 1. Replace the Fuser (page 8-11).
2.Does the error still occur?
Replace the
MCU Board
(
page 8-86).
Complete.
