10-24 Phaser 6280 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
Signal Line Name Description
PAPER EMPTY SENSED
(L) +3.3 VDC
Paper detects signal of the Tray 1 (MPT) by the Photo
Sensor (Tray 1 (MPT) No Paper Sensor).
REGI SENSED (L) +3.3
VDC
Paper detects signal of the Registration area by the
Photo Sensor (Registration Sensor).
REGI CL ON (L) +24 VDC On/Off signal of the Regi Clutch.
FEED SOL ON (L) +24 VDC On/Off signal of the Tray 1 (MPT) Feed Solenoid.
TEMP. Data on temperature inside the printer.
PH MOT ON (X) +XX VDC Drives control signal of the PH Drive Assembly.
PH MOT CLK
PH MOT ALARM
