Xerox Phaser 6280 Service Manual

10-42 Phaser 6280 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
Signal Line Name Description
Txd Controls signal of the Duplex Board.
Rxd
DUP MOT A Drives control signal of the Duplex Motor.
DUP MOT B
DUP MOT XA
DUP MOT XB
DUP IN SENSED (L) +3.3
VDC
Paper detects signal of the Duplex by the Photo Sensor
(Duplex Jam Sensor).
DUP CL ON (L) +24 VDC On/Off signal of the Duplex Clutch.
FAN +24 VDC Drives control signal of the Duplex Fan.
FAN ALARM

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
