3-28 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Error Messages and Codes
14 Test the Feed Solenoid.
Run the Service Diagnostics Feed Solenoid
test.
Does the solenoid function correctly?
Check the feed
solenoid
stopper and
replace if
necessary.
Go to Step 15.
15 Check for +24 V to the Feed Solenoid.
1. Disconnect P/J824
2. Close the Interlock Switch while testing.
Is there +24 V across P824-2 <+>ground?
Go to Step 17. Go to Step 16.
16 Check all pins on the OPFDR Harness
PL12.3.7 for continuity.
1. Disconnect P/J85 and P/J824.
2. Check continuity between J85 <=>
P824.
Go to Step 17. Replace the
OPFDR
Harness.
17 Test the Feed Solenoid resistance.
Disconnect P/J824.
Is J824-1 <=> J824-2 less than 100Ω?
Go to Step 17. Replace the
Feed Solenoid
(Part of the
Paper Pick
Assembly).
18 Check all pins on the OPFPLG Harness
PL3.2.11 for continuity.
1. Disconnect P/J171 and P/J17.
2. Check continuity between P171 <=>
J17.
Replace the
Engine Control
Board
(
page 8-106).
Replace the
OPFPLG
Harness
(
page 8-29).
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
