Phaser 6300/6350/6360 Color Laser Printer Service Manual 1-3
General Information
Printer Configurations
The Phaser 6300/6350/6360 printer is available in five configurations. The
main differences are standard memory, optional high-capacity feeders,
duplexing (2-sided printing) capabilities, and optional internal hard drive. The
following table lists the available configurations.
Features
Printer Configuration
6300N/
6360N
6300DN/
6360DN
6350DP
6350DT/
6360DT
6350DX/
6360DX
Max Print Speed
(ppm) color/
mono
26/36
42/42
26/36
42/42
36/36 36/36
42/42
36/36
42/42
Hard Drive Optional Optional Optional Optional Yes
Standard
Memory*
256 MB 256 MB 256 MB 512 MB 512 MB
USB Port Yes Yes Yes Yes Yes
10/100 Ethernet Yes Yes Yes Yes Yes
RAM Collation Yes Yes Yes Yes Yes
Duplex Unit No Yes Yes Yes Yes
PostScript and
PCL Fonts
Yes Yes Yes Yes Yes
Banner Sizes Yes Yes Yes Yes Yes
Photo Mode** Yes/
No
Yes/
No
Yes Yes/
No
Yes/
No
Resolutions
(dpi):
Standard
Enhanced
Photo**
1200x600
2400x600
1200x1200
1200x600
2400x600
1200x1200
1200x600
2400x600
1200x1200
1200x600
2400x600
1200x1200
1200x600
2400x600
1200x1200
Tray 1 (MPT) Yes Yes Yes Yes Yes
Tray 2 Yes Yes Yes Yes Yes
550-Sheet
Feeder***
Optional Optional Optional Yes Optional
1100-Sheet
Feeder***
Optional Optional Optional Optional Yes
* All configurations have two memory slots supporting 256 MB and 512 MB cards, to a
maximum of 1 GB.
** Photo Mode not available on Phaser 6360
***Trays 1 and 2 are standard on all configurations. All configurations support additional
paper trays in the following combinations:
One 550-sheet feeder (Tray 3)
One 1100-sheet high-capacity feeder (Trays 3 and 4 or 4 and 5)
One 550-sheet feeder (Tray 3) and one 1100-sheet feeder (Trays 4 and 5)

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
