Xerox Phaser 6360 Service Manual

1-14 Phaser 6300/6350/6360 Color Laser Printer Service Manual
General Information
Functional Specifications
Functional Specifications
Characteristic Specification
Printing
Process
Imaging System: - 4-tandem drums, electro-photographic system
using intermediate drum transfer rolls (IDTs).
Exposure System: - Semiconductor laser, simultaneous scan by 4
beams.
Development System: - Dry type 2-component developer.
Fusing System: - Heat fusing, free nip-belt system.
Color Medium Yellow, Magenta, Cyan, and Black Toner Cartridges
Resolution /
Addressability
Standard
Enhanced
1200 x 600 dpi (default)
2400 x 600 dpi
1200 x 1200 dpi (not on 6360)
Operating
Modes
Print Mode: Print Engine capable of making prints immediately.
Ready Mode: 20 seconds from completion of a print.
Sleep/ Low Power/ Power Saver Mode: Entered after a specified
period of inactivity since completion of the last print.
Maximum
Color
Coverage
6300N and DN configurations is 240% at 26 ppm
6350DP, DT, and DX configurations is 200% at 36 ppm
6360 all configurations is 200% at 42 ppm
Print Speed Phaser 6350DP, 6350DT, and 6350DX Configurations
Resolution Letter/A4 Letter/A4 Duplex
(ipm)
Legal Legal Duplex
(ipm)
Standard:
Enhanced:
Photo:
Transparencies
100-163 g/m
2
163-216 g/m
2
36/35
26/24
18/18
12
18/18
12
21/20
15/15
11/11
N/A
11/11
N/A
29
20
12
N/A
12
8
20
13
8
N/A
8
N/A
Print Speed Phaser 6300N and 6300DN Configurations
Resolution Letter/A4 Letter/A4 Duplex
(ipm)
Legal Legal Duplex
(ipm)
Standard:
Enhanced:
Photo:
Transparencies
100-163 g/m
2
163-216 g/m
2
26/24
26/24
18/18
12
18/18
12
15/15
15/15
11/11
N/A
11/11
N/A
20
20
12
N/A
12
8
13
13
8
N/A
8
N/A

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
