Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Service Manual 4-27
General Troubleshooting
USB Port Testing
In situations where USB communications fail, test the printer’s USB Port
directly using a USB cable and a second, known good, USB Port. A
successful test using this procedure eliminates the printer’s USB Port as the
root cause.
Initial Actions:
■ Check that the driver software is properly installed on the host.
■ Make sure the USB cable is connected at both ends and is serviceable.
■ Print a Configuration page and verify that USB 2.0 is enabled in the
printer’s NVRAM.
■ Reboot the printer.
■ If the problem persists, follow the procedure below.
N
o
t
e
The testing procedure was developed for Windows XP. If a different
operating system is in use, adapt the steps as necessary.
1. Verify that the printer is Ready To Print.
2. Insert the Phaser 6300/6350/6360 Installer and Utilities CD-ROM into the
computer.
3. If the installer autoruns, exit the installer window.
4. Connect a USB cable between the printer and computer’s USB Ports. The
computer automatically detects the new hardware and creates a driver.
Note
If the driver is not installed on the computer, locate the driver files on
the CD-ROM. Once the files are located, the computer installs the
driver and automatically configures it to match the printer’s feature
set.
5. Open the Printers and Faxes window on the computer by clicking Start,
Settings, and then Printers and Faxes.
6. Locate the correct entry for the printer being tested and display its
properties from the File menu pull-down.
7. Open the General tab and click the Print Test Page button to generate
the test print. If the test page prints, the USB port is functioning normally.

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
