9-62 Phaser 6300/6350/6360 Color Laser Printer Service Manual
Parts List
Sensor Acutator Kit
The Sensor Actuator Kit provides replacement actuators for the key paper
path sensors. Two versions of the Sensor Actuator Kit are available. For 6300/
6350 models, use P/N 116-2032-00. For 6360 models use P/N 604K38490.
Repalcement springs for most of these actuators are included in the Kit.
Long-Life Maintenance Kit
Install the Long-Life Maintenance Kit when the printer displays the Replace
Maintenance Kit error message. Two versions of the Long Life Maintenance
Kit are available. For 6300/6350 models, use P/N 650-4363-00. For 6360
models use P/N 604K48020.
Sensor Actuator Kit Contents - 116-2032-00 or 604K38490
Part Reference Name/Description Quantity
PL3.3.14 Low Paper Sensor Actuator 2
PL3.3.20 No Paper Sensor Actuator 2
PL4.1.1 Registration Sensor Actuator 1
PL5.1.2 Fuser Exit Sensor Actuator 1
PL5.3.15 Tray 1 (MPT) No Paper Sensor Actuator 1
PL5.4.2 Full Stack Sensor Actuator 1
PL5.4.13 Duplex Jam Sensor Actuator 1
Long-Life Maintenance Kit Contents - 650-4363-00 or 604K48020
Part Reference Name/Description Quantity
PL2.1.12 Universal Tray Retard Roller Assembly 1
PL4.1.13 Tray 1 (MPT) Retard Roller Assembly 1
PL4.2.1 Registration Roller Assembly 1
PL5.3.20 Tray 1 (MPT) Feed Roller 1
PL7.1.17 Developer Assembly - Y 1
PL7.1.18 Developer Assembly - M 1
PL7.1.19 Developer Assembly - C 1
PL7.1.20 Developer Assembly - K 1

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
